Enable-IT 8908 8 Port Extended Ethernet DSLAM

MSRP $1100 1U Desktop Gigabit Extender Ethernet DSLAM

The PLANET's most trusted and deployed brand since 1982.
Delivers Ethernet LAN Extender over SEVENTY-THREE times further than IEEE 802.3 specs.
Ideal for long distance deployments of LAN infrastructure.
Leverage any 1-pair wiring (CAT rated or Coax) up to (24,000ft) or (7.31km).
Supports up to 8 individual CPE units in a small tabletop enclosure. NO Competitor product can do this.
Secure and Encrypted Communications between End-To-End devices.
ENABLE-IT USA AS9100D Aerospace Quality Factory Floor Direct Same Day Shipping.


DESIGNED & MADE IN THE USA WITH QUALITY AND PRIDE.
PROFESSIONAL BUSINESS GRADE PERFORMANCE,
RUGGEDIZED EXTREME TEMPERATURE ENCLOSURE,
ENCRYPTED AND SECURE.


Don't risk your business data to cheap, low quality imported LAN equipment!
Protect the value of your LAN data and company secrets.
Beware of competitors as some are banned in the USA due to spyware.
Insist on the Enable-IT Brand, trusted by security experts worldwide.

In-Stock NOW Product UPC: 896741002201 [wp-review]

This will also add the following products to your cart:

  • $3.34/mo for a 4yr Advanced Replacement 8908 Concentrator Next Business Day
Request a Quote Quote from Resellers
SKU: 8908 Category:
The Enable-IT™ 8908 Gigabit Extended Ethernet Concentrator (Ethernet DSLAM) is the highest-throughput encrypted and Secure extended Ethernet solution on the planet bar none! Delivering your network up to THIRTY-SIX times further than Ethernet's stifling limit of just 328 feet.

Using your old 1-pair telephone wiring (or better), the 8908 Gigabit Ethernet DSLAM can extend your Ethernet all the way up to 4.54 Miles (24,000ft) or 7.31km, effectively saving you thousands in labor, administration, and security.

The Enable-IT 8908 Ethernet DSLAM drives Gigabit Ethernet and optional voice through existing telephone lines to the 8 ports of Gigabit switched quad port Enable-IT 850 Gigabit CPE units. The Enable-IT 8908 Ethernet DSLAM aggregates its upstream and downstream bandwidth through a pair dedicated Gigabit ports (copper or GBIC fiber modules) to your Ethernet switching equipment or routers. This 8908 8-port DSLAM unit offer a significant cost savings for deploying multiple Ethernet Extension runs from a single location and can be rackmounted for convenience.


Ideal for providing Internet access to multi-unit properties like Hotels, outdoor camps, Office complexes, Apartments, Campus Dormitories, Ski Resorts, Stadiums, Shopping Malls Trailer parks, Marinas and Cruise Ships.


This is trusted Business Reliable Professional Grade Gigabit Extended Ethernet Concentrator (Ethernet DSLAM) without the high cost of fiber or unsecure wireless. Why risk your business to lower quality imported equipment? The value of your network communications should be a protected investment. Beware of Cheap Chinese "so called Business Use" (not even suitable US Home use) gear that is banned in the US due to proven hidden spyware.

Enable-IT is the seminal creator and inventor of Ethernet Extender and PoE Extender concepts and technology. We are the original trusted source.

The US Federal Govt has banned most all non-US made networking products in their networks - Why risk your business using cheap foreign LAN products?

Try the world's fastest performing and most cost effective Ethernet DSLAM and PoE DSLAM Solutions -


Designed and Made in our USA AS9100D Aerospace Quality Production Facilities.

Professional Business Grade Product, Solid reliability not Chinese Home Use crap.

Includes the Industry leading Limited Lifetime Manufacturer Warranty.

Optional 4 year Next Business Day Advanced Replacement for under $5 per month!
        What's the cost of your network being down?

Insured, Same Day Flat Rate Shipping - US Factory Floor Direct.

(8) individual extended Gigabit Ethernet lines in a single 8908 desktop controller.

Delivers 260Mbps over standard telephone wiring or better up to 1 Mile (3,500ft) or 1.06km.

RJ-45 LAN connection for insertion into existing 1-pair wiring.

LAN Device independence - Transparent to 802.3 Protocols, Applications.
      and MAC / IP addresses.

Enable-IT 850 CPE uses RJ-45 LAN jacks and no programming required.

LAN Device independence - Transparent to 802.3 Protocols, Applications.
      and MAC / IP addresses.

Enable-IT 850 Gigabit CPE with Quad LAN ports on each end eliminates the need for LAN switches.


This kit includes the following:
(1) Desktop Enable-IT 8908 Gigabit DSLAM - (8) RJ-45 2-wire connectors.
(1) Country Specific 12V - 2A DC Power Adapter
(1) Out of band Management Gigabit EthernetPort
(1) Mini Gigabit GBIC uplink port
(1) Serial Console port
► Same Day Flat Rate Shipping - US West Coast Factory Floor Direct
► Lifetime Manufacturer Warranty
► Optional 4yr Next Business Day Advanced Replacement

Power

AC Input: (90~254V) @50/60Hz to 12V DC Wall adapter included.
Power Consumption 15 watts / 51 BTU

LED Display

8908 Operating Status : 8908 Power / System status
LINK/ACT : 850 CPE sync status / Data TX/ RX
Gigabit Uplinks Copper / Mini-GBIC : 10/100/1000 Base-TX Speed

Data Rate

1,000Mbps full-duplex Ethernet Data
260Mbps Interconnect throughput

Interface

(1) Gigabit uplink port
(1) Mini GBIC port
(1) Serial Console port
(1) Out of band Management Port

Dimensions

Height 1.73" (44mm) Depth 6.75" (172mm) Width 10.5" (267mm)

Environment

Operational Temperature: -49°F to 168°F (-45°to 76°C)
Humidity: 5% to 95%, non-condensing

Enclosure

Ruggedized desktop casing Optimized for heat extraction and simplicity.

Standards

VDSL2 ITU-T G.993.2
802.1d L2 Bridging
DHCP /Client/Relay/Option82
IEEE 802.1q VLAN Tag base
VLAN Stacking (Q-in-Q)
IEEE 802.1d Spanning Tree Protocol (STP)
IEEE 802.3ad Link Aggregation Support:
IGMP Snooping/Proxy v1, v2 and v3
Multicast Forwarding with IGMP Snooping v1 and v2 (RFC 1112 and RFC 2236)
Multicast MAC address mapping
Up to 512 Multicast Channels
Profile-based Multicast Access Control
Security:
L2 Frame Filtering by MAC Addresses
L3 Frame Filtering by IP Addresses, protocol ID, and TCP/UDP
DHCP and ARP Broadcasting Frames Filtering
Support Secured Forwarding
Management:
Local Management: RS-232 and Telnet CLI,
Web/SNMP management.
Remote in-band Management: Web/SNMP/Telnet
Support SNMP v1/v2/v3

Datasheet ►      Datasheet pdf

Quickstart Guide ►      Datasheet pdf

Product Manual ►      Datasheet pdf

ENABLE-IT 8908 DSLAM Wiring Diagram
ENABLE-IT 8908 DSLAM WIRING DIAGRAM
