ENABLE-IT 8805 5 PORT GIGABIT POE SWITCH

MSRP $90    5 Port High Power Gigabit PoE Switch with Smart PoE Detect
► The PLANET's most trusted and deployed brand since 1982
► 4-Ports Auto PoE power detect for safely attaching non-PoE devices
► Ideal for installing high power PoE devices (WiFi Access Points or IP Cameras)
► Delivers up to 48V DC 30W per port of IEEE 802.3af 2-pair PoE power
Minimal size for easy concealment or use in an outdoor protective enclosure
► Core Gigabit Backplane allows for up to 2 Gbps per port (Full Duplex)
► 2k MAC addressing, 4k VLAN addressing supported
► Any CUSTOM option available at time of order
► ENABLE-IT USA Factory Floor Direct Same Day Shipping


Post Install Ratings[yasr_overall_rating size=”small”]

Request a Quote Quote from Resellers
SKU: 8805 Category: Tag:
The Enable-IT 8805 Gigabit PoE Switch is a unique product. It can automatically detect any LAN device and determine if it is a PoE device and supply power with IEEE 802.3af standard voltage and watts.

The Enable-IT 8805 Gigabit PoE Switch has 4 dedicated 10/100/1000Mbps Auto-Negotiation RJ-45 LAN ports with each port PoE auto detect enabled. Auto detect PoE uses IEEE 802.3 PoE Power Detection (PD). There is no need to worry about the damage of PoE being applied to Non-PoE Devices and PoE connected devices are supplied with up to 30W per port.

The Gigabit PoE Switch supplies PoE electrical power on industry standard 2-pair (RJ-45 pins 4/5 positive and 7/8 negative) along with Ethernet data in one single cable allowing you to expand your network where there are no power lines or outlets. This enable you to deploy PoE devices such as WiFi Access Points, PoE IP Cameras, PoE Access controls or PoE IP Phones.

This Gigabit PoE Switch supports Gigabit PoE extension up to 2,000ft by using our 828 Gigabit PoE Extender units.

► Professional Business Grade Product, Solid reliability not Chinese Home Use

► Includes a Industry leading 4 year Manufacturer Warranty

► Optional 4 year Next Business Day Advanced Replacement for under $2 per month

► Free Ground Shipping or Low cost Flat Rate 2nd Day / Overnight

► Ideal for high power PoE devices like WiFi Access Points or IP Cameras.

► Can deliver Up to 48V DC 30W per port of IEEE 802.3af 2-pair PoE power

► Micro size for easy concealment or in outdoor protective enclosure.

► Core Gigabit Backplane to Uplink port allows for up to 2 Gbps per port(Full Duplex) and 2k Mac addressing
  • (4) 10/100/1000Mbps Auto-Negotiation RJ-45 ports with PoE auto detect<
  • (1) Uplink 10/100/1000Mbps Auto-Negotiation RJ-45 ports
  • Complies with IEEE 802.3af/at standards
  • Each port supports full duplex auto-negotiation -10/20, 100/200, 1000/2000Mbps
  • Maximum Bandwidth backplane 10 Gbps
  • Supports PoE power up to 30W for each PoE port
  • Supports automatic-detect function to protect the system when the system power is overloaded or there is a non-PoE device
  • LED indicators for monitoring PoE power, Physical link, LAN activity and LAN speed
  • 48V 2A 60W power adapter included
    This kit includes the following:
    Professional Business Grade Product, Solid reliability not Chinese Home Use

    Includes a Industry leading 4 year Manufacturer Warranty

    Optional 4 year Next Business Day Advanced Replacement for under $2 per month

    Free Ground Shipping or Low cost Flat Rate 2nd Day / Overnight

    Power

    Country Specific power cord and 48V 2A 60W power adapter included

    Data Rate

    Gigabit full-duplex Ethernet Data & PoE (802.3af) or PoE (802.3at) High Power Gigabit PoE Switch 4 1 Port

    Interface

    Ethernet: (5) LAN RJ-45 Standard 10/100/1000BaseTX, MDI-X, Auto-negotiate ports.

    Dimensions

    Height .8″ (20mm) Depth 3.2″ (82mm) Width 3.5″ (92mm)

    Environment

    Operational Temperature: -40°F to 158°F (-40°to 70°C)
    Humidity: 5% to 90%, non-condensing

    Enclosure

    Ruggedized wall mount black Aluminum casing Optimized for heat extraction and isolation without fans.

    ENABLE-IT 8805 POE SWITCH

    DATASHEET ►


    QUICKSTART GUIDE ►


    MANUAL ►


    8805 Wiring
    ENABLE-IT 8805 WIRING

    ► Designed and Made in the USA

            Factory Direct Highest Quality Expert Product Engineering.
            Don't be fooled by foreign companies with US offices selling you cheap quality electronics from who knows where - Insist on USA made high quality equipment and support.

    ► Professional Grade Equipment - Trusted Reliability

            (Ruggedized, Extreme Distance, Highest Throughput, OEM Customizable, Encrypted and Secure)
            Since 1997, we have been manufacturing the highest quality Made in the USA Ethernet Extenders - US Factory Floor direct same day flat rate shipping.

    ► Lifetime Product Warranty

            Peace of Mind Longest Product Warranty in the industry - Limited Lifetime Product Warranty. Why would you waste your time and money with anything of inferior quality
            or from a company that doesn't stand behind it's own products?

    ► 45-Day Money Back Guarantee

            For those who wish to try our superior USA engineered Ethernet and or PoE technology, we offer a gracious 45-Day trial period when purchasing single unit kits per our policy here .

    ► Certified Spyware Free

            Buyer Beware! Knockoff competitors of our products have been banned by the US Govt for containing data stealing spyware.
            Our products are trusted in some of the most secure environments such as control of US Nuclear weapon systems through our national security contracts for the DOD and US Military.

    ► No Configuration - Plug and Go - Highest Throughput

            All of our products are ready ring out of the box. Simply connect the devices to your cabling and plug them in if they require a power adapter.
            There are no configuration parameters to set up! We even include your country-specific power adapters.
            Don’t settle for low bandwidth. And because we offer the highest speeds of any Ethernet Extender Manufacturer, we make sure you won’t have to.
            High performance without compromise – that’s what you’ll get.

    ► Same Day Flat Rate Shipping - FREE Ground shipping

            Our US West coast manufacturing factory floor processes all orders placed by 4:30pm PST and are expedited for same day shipping worldwide.
            Flat Rate Domestic US Shipping - Ground shipping is FREE - See our policy here .

    ► Next Business Day Advanced Replacement Service

            No other manufacturer in our industry can stand behind their products or services as well as Enable-IT does bar none.
            We offer a 4-Year peace of mind business continuity AREP (Next Business Day Advanced Replacement). - See our AREP policy.

    ► US Based Expert Technical Support and Customer Care Team

            No need to speak Mandarin or Urdo and or wait days to get timely support to technical questions answered.
            Our Expert Technical Customer Care Team along with our OEM Design engineers and manufacturing operations are all Proudly USA In-house.
            We take great pride in listening to and understanding your needs and providing professional timely support.

    ► Custom USA Made OEM Solutions

            If you need a design or specifications that are not in one of our products, our OEM Design engineers and manufacturing operations are all Proudly USA In-house.
            We can create tailored OEM solutions in days with minimum 10 unit quantity orders. Enable-IT can give you a strategic advantage in your marketplace - Try Us
